40' 高顶冷箱 (A)
  • DAIKIN/LXE10E-A18*(-A144B)
  • 40' * 8' * 9'6" REEFER HIGH CUBE













Weight
Tare 4,710 kgs 10,380 lbs
Payload 27,790 kgs 61,270 lbs
Gross Weight 32,500 kgs 71,650 lbs
Weight (* Start from YMLU526296 )
Tare 4,850 kgs 10,690 lbs
Payload 29,150 kgs 64,270 lbs
Gross Weight 34,000 kgs 74,960 lbs
Door Opening
Width 2,290 mm 7' 6.2"
Height 2,569 mm 8' 5.1"
Inside Cubic 67.7 cu.m. 2,390 cu.ft.
Measure Overall Inside
Length 12,192 mm 40' 11,577 mm 37' 11.8"
Width 2,438 mm 8' 2,294 mm 7' 6.3"
Height 2,896 mm 9' 6" 2,546 mm 8' 4.2"
  • * Machine maker : Daikin
    Setting Temperature range (suggestion) : -20°C to +25°C
    Fresh air exchange : Max 250 m3/hr <60Hz>
    Refrigerant type : R-134A
    DeHumidification : Activate when following conditions are all satisfied
    1) Dehumidification is ON/Active
    2) Temperature is in range
40' 高顶冷箱 (B)
  • DAIKIN/LXE10E-144C
  • 40' * 8' * 9'6" REEFER HIGH CUBE








Weight
Tare 4,630 kgs 10,210 lbs
Payload 29,370 kgs 64,750 lbs
Gross Weight 34,000 kgs 74,960 lbs
Door Opening
Width 2,290 mm 7' 6.2"
Height 2,569 mm 8' 5.1"
Inside Cubic 67.7 cu.m. 2,388 cu.ft.
Measure Overall Inside
Length 12,192 mm 40' 11,590 mm 38' 0.3"
Width 2,438 mm 8' 2,294 mm 7' 6.3"
Height 2,896 mm 9' 6" 2,544 mm 8' 4.2"
  • * Machine maker : Daikin
    Setting Temperature range (suggestion): -25°C to +25°C
    Fresh air exchange : Max 250 m3/hr <60Hz>
    Refrigerant type : R-134A
    DeHumidification : Activate when following conditions are all satisfied
    1) Dehumidification is ON/Active
    2) Temperature is in range
    3) RH act > RH set (setting range: 60% ~ 95%, start from YMLU5374964 )
    *Due to various ambient & cargo condition, RH act can't be controlled precisely as setting request when Dehumidification is activated.
40' 高顶冷箱 (C)
  • STARCOOL/SCI-40
  • 40' * 8' * 9'6" REEFER HIGH CUBE (*Integrated)








Weight
Tare 4,460 kgs 9,830 lbs
Payload 29,540 kgs 65,130 lbs
Gross Weight 34,000 kgs 74,960 lbs
Door Opening
Width 2,290 mm 7' 6.2"
Height 2,557 mm 8' 4.7"
Inside Cubic 67.5 cu.m. 2,384 cu.ft.
Measure Overall Inside
Length 12,192 mm 40' 11,588 mm 38' 0.2"
Width 2,438 mm 8' 2,290 mm 7' 6.2"
Height 2,896 mm 9' 6" 2,545 mm 8' 4.2"
  • * Machine maker : Starcool
    Setting Temperature range (suggestion) : -25°C to +25°C
    Fresh air exchange : Max 220 m3/hr <60Hz>
    Refrigerant type : R-134A
    DeHumidification : Activate when following conditions are all satisfied
    1) Dehumidification is ON/Active
    2) Temperature is in range
    3) RH act > RH set (setting range: 65% ~ 95% )
    *Due to various ambient & cargo condition, RH act can't be controlled precisely as setting request when Dehumidification is activated.
40' 高顶冷箱 (D)
  • THERMO KING/MAGNUM+
  • 40' * 8' * 9'6" REEFER HIGH CUBE








Weight
Tare 4,460 kgs 10,270 lbs
Payload 30,340 kgs 66 ,890 lbs
Gross Weight 35,000 kgs 77,160 lbs
Door Opening
Width 2,290 mm 7'-6 5/32"
Height 2,569 mm 8'-5 9/64"
Inside Cubic 67.0 cu.m. 2,367 cu.ft.
Measure Overall Inside
Length 12,192 mm 40' 11,590 mm 38'- 19/64"
Width 2,438 mm 8' 2,280 mm 7'-5 49/64"
Height 2,896 mm 9' 6" 2,537 mm 8'-3 7/8"
  • * Machine maker : Thermoking
    Setting Temperature range (suggestion) : -35°C to +30°C
    Fresh air exchange : Max 225 m3/hr <60Hz>
    Refrigerant type : R-404A
    DeHumidification : Activate when following conditions are all satisfied
    1) Dehumidification is ON/Active
    2) Temperature is in range
    3) RH act > RH set (setting range: 60% ~ 99%)
    *Due to various ambient & cargo condition, RH act can't be controlled precisely as setting request when Dehumidification is activated.
40' 高顶冷箱 (E)
  • DAIKIN/LXE10E-136H
  • 40' * 8' * 9'6" HIGH CUBE REEFER








Weight
Tare 4,750 kgs 10,470 lbs
Payload 30,250 kgs 66 ,690 lbs
Gross Weight 35,000 kgs 77,160 lbs
Door Opening
Width 2,290 mm 7'-6 5/32"
Height 2,569 mm 8'-5 9/64"
Inside Cubic 67.4 cu.m. 2,380 cu.ft.
Measure Overall Inside
Length 12,192 mm 40' 11,590 mm 38'- 19/64"
Width 2,438 mm 8' 2,284 mm 7'-5 59/64"
Height 2,896 mm 9' 6" 2,545 mm 8'-5 23/64"
  • * Machine maker : Daikin
    Setting Temperature range : -25°C to +20°C
    Fresh air exchange : Max 225 m3/hr <60Hz>
    Refrigerant type : R-134A
    DeHumidification : Activate when following conditions are all satisfied
    1) Dehumidification is ON/Active
    2) Temperature is in range
    3) RH act > RH set (setting range: 60% ~ 95%)
    *Due to various ambient & cargo condition, RH act can't be controlled precisely as setting request when Dehumidification is activated.
